Leupold Mark 4HD 1-4.5x24 Rifle Scope M1C3 SFP HPR-1 Reticle
Leupold Mark 4HD 1-4.5x24 Rifle Scope M1C3 SFP HPR-1 Reticle
Couldn't load pickup availability
Leupold Mark 4HD 1–4.5×24 Rifle Scope M1C3 SFP HPR-1 Reticle
Features
- Low-Power Variable: 1–4.5× zoom ratio via slim throw-lever for rapid transitions between close-quarters and mid-range shots.
- Professional-Grade Optics: Fully multi-coated lenses and prisms (Xtended Twilight® system) deliver exceptional light transmission, glare reduction, and edge-to-edge clarity.
- HPR-1 Second Focal Plane Reticle: Glass-etched MIL-rad “High Power Rifle” pattern calibrated for service-rifle ballistics; non-illuminated to conserve power.
- M1C3 Adjustment Turrets: Exposed, finger-click elevation turret with one full revolution plus 3 MIL travel; positive ZeroLock® windage cap prevents accidental shift.
- Side Focus Parallax: Quick-set focus dial on the left side brings targets into tack-sharp focus from 25 yd to infinity.
- Robust 30 mm Main Tube: CNC-machined 6061-T6 aluminum; waterproof, fog- and shock-proof (rated to .50 BMG recoil).
- Compact & Lightweight: At just 10.7″ (272 mm) and 24.3 oz (688 g), adds minimal bulk to AR-style rifles.
Technical Specifications for Leupold Mark 4HD 1–4.5×24 Rifle Scope M1C3 SFP HPR-1 Reticle
Specification |
Details |
Model / MPN |
Mark 4HD 1–4.5×24 M1C3 SFP HPR-1 (183314) |
SKU |
183314 |
UPC |
030317036331 |
Magnification |
1× ⇄ 4.5× |
Objective Lens Diameter |
24 mm |
Main Tube Diameter |
30 mm |
Reticle |
HPR-1 (SFP, MIL-rad ballistic pattern) |
Turret Adjustment |
0.1 MIL per click; elevation: 1 rev + 3 MIL total; windage under ZeroLock® cap |
Parallax Focus |
Side focus, 25 yd–∞ |
Eye Relief |
3.7″–3.9″ (94–99 mm) |
Field of View @ 100 yd |
103 ft (1×) ⇄ 23 ft (4.5×) |
Length |
10.7″ (272 mm) |
Weight |
24.3 oz (688 g) |
Finish / Housing |
Matte-black hard-coat anodize; 6061-T6 aluminum |
Waterproof / Fogproof |
Yes (IPX7) |
Shock Resistance |
Rated to withstand .50 BMG recoil |
Battery |
None (non-illuminated reticle) |
Included Accessories
- Integrated magnification throw lever
- ZeroLock® windage cap
- Lens covers
- User manual
