Holosun DRS-TH Thermal Reflex Sight
Features
- Thermal Fusion Overlay: Seamlessly combines a 256 × 192 thermal sensor feed with a crisp 2 MOA red-dot reticle (circle, dot, or circle+dot) on a 1024 × 768 OLED display at 50 FPS.
- Digital Magnification: Choose 1×, 3×, or 5× electronic zoom in thermal modes for enhanced target identification.
- Multi-Reticle System™ (MRS): Select between 2 MOA dot only, 65 MOA circle only, or both combined for versatile aiming.
- On-Board Recording: Capture photos and video directly to internal storage—no SD card required.
- Rechargeable Power: Two 18350 Li-ion batteries deliver up to 10 hours of continuous thermal operation; recharge in-unit via USB-C.
- Solar Failsafe™ & Shake Awake®: Integrated solar panel backup and motion-activated on/off extend total runtime and ensure instant power-up.
- Rugged Construction: CNC-machined 7075-T6 aluminum housing, hard-coat anodized; IP67-rated waterproof and dustproof; shock- and vibration-proof.
- Tool-Free Mounting: Low-profile Picatinny clamp with 11 mm nut mounts quickly without tools.
- Unlimited Eye Relief & Parallax-Corrected: True 1× reflex sight optics with a large viewing window for rapid acquisition.
Holosun DRS-TH Thermal Reflex Sight – Technical Specifications
|
Specification |
Details |
|
Model / MPN |
DRS-TH |
|
SKU |
DRS-TH |
|
UPC |
810047072935 |
|
Thermal Sensor Resolution |
256 × 192 |
|
Display Resolution |
1024 × 768 OLED @ 50 FPS |
|
Thermal Modes |
White-Hot, Black-Hot, Highlight, Outline, Fusion |
|
Digital Zoom |
1×, 3×, 5× |
|
Reticle Options (MRS) |
2 MOA dot / 65 MOA circle / circle+dot |
|
Illumination |
Red Super LED |
|
Brightness Levels |
8 daylight / 4 NVG |
|
Battery |
2 × 18350 rechargeable Li-ion; USB-C charging; ≈10 hr runtime |
|
Solar Failsafe™ |
Yes |
|
Shake Awake® |
Yes |
|
Optical Magnification |
1× |
|
Viewing Window |
1.25″ × 0.98″ (31.8 × 24.9 mm) |
|
Eye Relief |
Unlimited |
|
Parallax |
Corrected |
|
Mount Interface |
MIL-STD-1913 Picatinny; tool-free clamp (11 mm nut) |
|
Housing Material |
CNC-machined 7075-T6 aluminum, hard-coat anodize |
|
Waterproof/Dustproof |
IP67 |
|
Weight |
18.5 oz (525 g) |
|
Dimensions (L × W × H) |
3.7″ × 2.2″ × 3.5″ (94 × 56 × 89 mm) |
|
Operating Temperature |
–20 °C to 60 °C |
|
Country of Origin |
China |
