Leupold
Leupold VX-Freedom 3-9x40 CDS Rifle Scope TRI-MOA Reticle
Leupold VX-Freedom 3-9x40 CDS Rifle Scope TRI-MOA Reticle
Couldn't load pickup availability
Leupold VX-Freedom 3–9×40 CDS Rifle Scope Tri-MOA Reticle
(Model 180603)
Features
- 3:1 Zoom Ratio: Fast-throw magnification lever for swift changes between 3× (wide field) and 9× (precision).
- Advanced Optical System: Fully multi-coated, extra-low-dispersion glass with Leupold’s Twilight Light Management System for excellent brightness, glare reduction, and edge-to-edge clarity.
- Tri-MOA® Reticle (Second Focal Plane): Three-post MOA design with 1 MOA hash-marks—subtends true at maximum magnification for intuitive hold-over and wind-hold.
- Custom Dial System® (CDS®): Push-button lockable elevation dial with zero-stop return to zero; allows pre-set ballistic drops via optional CDS Custom Dial™ turrets.
- Precise Adjustments: ¼ MOA per click; 60 MOA total travel each for both windage and elevation.
- Long Eye Relief: 4.2″ (107 mm) at 3× → 3.7″ (94 mm) at 9× for comfortable, consistent cheek welds.
- Rugged Construction: CNC-machined 1″ (25.4 mm) main tube of 6061-T6 aluminum; matte-black hard-coat anodize; 100% waterproof, fog-proof, and shock-proof; recoil-rated for heavy calibers.
- Made in USA & Lifetime Guarantee
Technical Specifications for Leupold VX-Freedom 3–9×40 CDS Rifle Scope Tri-MOA Reticle
Specification |
Details |
Model / MPN |
180603 |
SKU |
180603–Leupold |
UPC |
030317028374 |
Country of Origin |
USA |
Tube Diameter |
1″ (25.4 mm) |
Magnification Range |
3 × ⇄ 9 × |
Objective Lens Diameter |
40 mm |
Reticle |
Tri-MOA® (SFP, non-illuminated) |
Focal Plane |
Second focal plane |
Parallax Focus |
Fixed at 100 yd |
Eye Relief |
4.2″ (107 mm) @ 3× ⇄ 3.7″ (94 mm) @ 9× |
Field of View @ 100 yd |
33.1 ft @ 3× ⇄ 13.6 ft @ 9× |
Elevation Adjustment |
¼ MOA/click; 60 MOA total travel |
Windage Adjustment |
¼ MOA/click; 60 MOA total travel |
Length |
12.39″ (314 mm) |
Weight |
12.2 oz (346 g) |
Finish |
Matte-black hard-coat anodize |
Waterproof / Fog-Proof |
Yes |
Shock-Proof |
Yes |
Included Accessories
- Removable fast-throw magnification lever
- Alumina® flip-up lens covers (40 mm)
- CDS adjustment tool
- Cleaning cloth
- User manual
