Primary Arms
Primary Arms GLx 34mm Cantilever Scope Mount - 20 MOA
Primary Arms GLx 34mm Cantilever Scope Mount - 20 MOA
Couldn't load pickup availability
Primary Arms GLx 34 mm Cantilever Scope Mount - 20 MOA
Features
- 20 MOA Built-In Cantilever – 20 MOA of forward elevation built into the mount provides extra elevation for long-range engagements without shims.
- 1.5″ Forward Offset – Positions 34 mm scopes at the ideal eye relief for AR-style platforms without requiring rearward rings.
- CNC-Machined 6061-T6 Aluminum – One-piece mount body in matte-black Type III hard-anodized finish for maximum strength and corrosion resistance.
- MIL-STD-1913 Picatinny Interface – Integrated rail clamp with dual cross-bolts ensures rock-solid retention and repeatable zero under heavy recoil.
- Tool-Free Installation – Oversized hex-head clamp screws allow quick mounting and removal with the included 5/32″ hex key while maintaining perfect alignment.
- Recoil-Stop Inserts – Factory-installed recoil-stop inserts prevent any slippage on the rail during rapid-fire sequences.
- Low-Profile Design – Slim footprint adds minimal height, preserving clearance for backup iron sights and other rail-mounted accessories.
Technical Specifications for Primary Arms GLx 34 mm Cantilever Scope Mount - 20 MOA
Specification |
Details |
Manufacturer |
Primary Arms |
Model / Part Number |
910083 |
SKU / MPN |
PA-GLX-CM-34-1.5-20 |
UPC |
818500015482 |
Tube Diameter |
34 mm |
Offset |
1.5 in (38 mm) forward |
Built-In Cantilever |
20 MOA |
Material |
6061-T6 aluminum |
Finish |
Matte-black Type III hard-anodize |
Rail Interface |
MIL-STD-1913 Picatinny |
Clamp Screws |
2 × M5 hex-head (5/32″ hex key included) |
Recoil-Stop Inserts |
Included |
Height Above Rail |
1.2 in (30 mm) |
Weight |
8.3 oz (235 g) |
Warranty |
Lifetime warranty |
Included Accessories
- 5/32″ hex key
- Recoil-stop inserts
- Instruction manual & warranty documentation
