Trijicon ACOG 3.5×35 BAC Riflescope .223/5.56 BDC Green Chevron Reticle
Features
- Dual-Source Illumination: Fiber-optic for automatic daytime brightness paired with tritium for constant low-light glow—battery-free, always-on, optimized for both-eyes-open Bindon Aiming Concept™ acquisition.
- 3.5× Fixed Magnification: Balances close-quarters speed with mid-range precision.
- .223/5.56 BDC Green Chevron Reticle: Calibrated out to 800 m on flat-top .223/5.56 platforms, zero the chevron tip at 100 m for intuitive hold-over and range estimation.
- 30 mm Main Tube: CNC-machined 6061-T6 aluminum with matte-black hard-coat anodize; nitrogen-purged; waterproof/fog-proof.
- Fixed Parallax: Optimized at 100 m—no side-focus adjustment.
- Ergonomic Flat-Top Mount: Includes TA51™ “Rock-touch” quick-detach flattop adapter for rapid on/off attachment with repeatable zero.
- Combat-Proven Ruggedness: Shock-tested for calibers from .22 LR through .50 BMG; waterproof to 10 ft.
- Made in USA & No-Fault® Lifetime Warranty
Technical Specifications for Trijicon ACOG 3.5×35 BAC Riflescope .223/5.56 BDC Green Chevron Reticle
Specification |
Details |
Manufacturer |
Trijicon |
Model / MPN |
TA11F-G |
SKU |
TA11F-G |
UPC |
071930730461 |
Country of Origin |
USA |
Magnification |
3.5× |
Objective Lens Diameter |
35 mm |
Main Tube Diameter |
30 mm |
Eye Relief |
2.4″ (61 mm) |
Field of View |
1.5° (≈28.9 ft @ 100 yd) |
Exit Pupil |
10 mm |
Parallax |
Fixed @ 100 m |
Reticle |
Green Chevron BDC .223/5.56 (SFP) |
Illumination Source |
Fiber-optic + tritium (automatic) |
Mount |
TA51 flattop quick-detach adapter |
Length |
8.0″ (203 mm) |
Weight |
14 oz (397 g) |
Finish |
Matte-black hard-coat anodize |
Waterproof / Fog-Proof |
Yes (IPX7) |
Shock-Proof |
Yes (.22 LR–.50 BMG) |
Included Accessories
- TA51™ flattop quick-detach mount
- Lens covers (flip-up)
- Cleaning cloth & LensPen® tool
- Trijicon logo sticker
- User manual & warranty card
