Trijicon ACOG 4x32 BAC Riflescope .223/5.56 BDC Red Crosshair Reticle

Trijicon ACOG 4x32 BAC Riflescope .223/5.56 BDC Red Crosshair Reticle

$1,229.99 USD
$1,229.99 USD
Sale Sold out
Shipping calculated at checkout.

Trijicon ACOG 4×32 BAC Riflescope .223/5.56 BDC Red Crosshair Reticle

Features

  • Dual‑Illuminated, Battery‑Free: Fiber optics auto‑adjust reticle brightness in daylight; tritium provides a continuous glow in low/no light—no batteries required.
  • 4× Fixed BAC Combat Optic: Bindon Aiming Concept™ supports both‑eyes‑open speed for close work while preserving precise 4× magnification for mid‑range 5.56 engagements.
  • .223/5.56 BDC Red Crosshair Reticle: Fine illuminated crosshair with descending ballistic stadia scaled for common 5.56 NATO loads when zeroed at 100 m; simple, uncluttered holds to distance.
  • Rugged Forged 7075‑T6 Aluminum Housing: Combat‑proven durability—shock, recoil, and harsh‑environment resistant; fully sealed and fog‑proof.
  • Wide Situational FOV: 7° (36.8 ft @ 100 yd) helps track movers and maintain awareness.
  • ½ MOA External Adjusters: 2 clicks/inch @100 yd for quick zeroing without removing turret caps.
  • Waterproof & Nitrogen‑Purged: Built for field extremes.
  • Compact & Lightweight: Short 5.8″ body keeps carbines lively; ships ready for flattop install.
  • Made in USA & Backed by Trijicon Warranty.

Technical Specifications for Trijicon ACOG 4×32 BAC Riflescope .223/5.56 BDC Red Crosshair Reticle

Specification

Details

Manufacturer

Trijicon

Model / MPN

TA31‑CH / 100233

SKU

TA31‑CH

UPC

719307303386

Country of Origin

USA

Magnification

4× fixed

Objective Lens Diameter

32 mm

Optical Design

Fixed‑power prism (integral ACOG housing)

Reticle

Red Crosshair .223/5.56 BDC (dual‑illum fiber optic / tritium)

Illumination

Fiber (day) / tritium (night); battery‑free

Eye Relief

1.5″ (38 mm)

Field of View @ 100 yd

36.8 ft (7°)

Exit Pupil

8.1 mm

Adjustment Click Value

½ MOA (≈2 clicks/inch @100 yd)

Total Adjustment Range

~40 MOA windage & elevation

Parallax Focus

Fixed at 100 m (≈109 yd)

Overall Length

5.8″ optic body (≈7″+ installed w/ mount & caps)

Weight

9.9 oz optic‑only; ~15 oz class w/ TA51 mount & accessories (varies by package)

Housing Material / Finish

Forged aluminum; matte black hard anodize

Waterproof / Fog‑Proof

Sealed; nitrogen‑purged; duty waterproof

Shock Resistance

Combat‑rated for service calibers

Mount Interface

TA51 flattop Picatinny thumbscrew adapter (included)

Included Accessories

  • TA51 flattop Picatinny thumbscrew mount
  • Scopecoat / protective cover (package dependent)
  • Lens cleaning tool (LensPen® style)
  • Adjuster cap lanyard / hardware kit
  • Trijicon logo sticker
  • Owner’s manual & warranty documentation
